Bus Tracking

Manage Integration

Enable Product Integration

Select to enable the product integration on the user's campusM app.

No

Checkbox

Unselected

Product Integration Description

A description of the product integration for internal use.

Yes

String

Screen Title

The title that appears in the top header of the service.

No

String

Bus Tracking

Vendor

Vendor Name

Defines to which vendor the integration connects.

Yes

Drop-down list

Samsara

Samsara Configuration

This section contains the Samsara API details to define the API structure. You can test the API configuration. See Testing API Product Integration Configuration.

Authentication Type

Authentication type against the web service. The options are:

• No Auth

• Bearer token

Yes

Drop-down list

Bus Marker Size

This specifies the radius of the bus markers and user location marker on the map. The value sets the radius of the circle in meters.

No

Number

100

Bus Route Timeframe

Sets the timeframe to query for routes.

Yes

Number

8

Timezone

Sets the time zone for the routes.

Yes

Drop-down list

UTC

Look and Feel

Primary Theme Color

Select a color for the main elements on the page.

No

Color Picker

#444444

Secondary Theme Color

Select a color for the secondary elements on the page.

No

Color Picker

#6f8ea4

Text/Labels

Bus Tracking Header

Pager header

No

String

Bus Tracking

User's Current Position Message

This appears in the route list.

No

String

Your current position

User's Current Position Label

This appears in the popup for the map marker for the user's location.

No

String

This is your current location.

Route Name Label

Label used in the map marker popups

No

String

Route Name

Bus ID Label

Label used in the map marker popups

No

String

Bus ID

Bus Name Label

Label used in the map marker popups

No

String

Bus Name

Location Label

Label used in the map marker popups

No

String

Location

Stop Name Label

Label used in the map marker popups

No

String

Stop Name

Address Label

Label used in the map marker popups

No

String

Address

Scheduled Arrival Times Label

Label used in the map marker popups

No

String

Scheduled Arrival Times

Scheduled Departure Times Label

Label used in the map marker popups

No

String

Scheduled Departure Times

Live Sharing URL Label

Label used in the map marker popups

No

String

Live Sharing URL

Map Layer Bus Label

Label for the map layer associated with buses for a specific route

No

String

Buses

Map Layer Stop Label

Label for the map layer associated with stops for a specific route

No

String

Stops

Base Map Layer Label

Name of the base map layer

No

String

Standard

Error Message

Message to display when there's an error retrieving the data.

No

String

Unable to reach the service at this time. Please try again later.

Import/ Export Configuration

You can configure product integration and then export it to another campusM environment, for example, from sandbox to production or from preview to production.

Export

Create a JSON file with all product integration configurations.

No

Import

Use this option to load configuration from JSON of an exported product integration.

No
